Specifications
SPECIFICATIONS
Basic Specifications | ||
Model | AT-DPS600LQ-B | |
Capacity | 576Wh / 19.2V 30Ah (equivalent to 12.8V 45Ah) | |
AC Voltage | 240v | |
Rated Power | 600 | |
Surge Power | 1200 | |
THD | ≤3% | |
Cell Type | LiFePO4 (32700 3.2V 6AH) | |
Work Temp | Discharge -10–40℃ Charge 0-40℃ | |
PV Voltage Range | 12-28v | |
PV Charge Power | MAX30V 200W | |
Wall Charge Power | 300W | |
Charge Methods | ||
Utility Power Charge Time | 300W (2h 80%) | |
Solar Charge Time | max 200w (2.5h 80%) | |
Generator Charge | 300W (2h 80%) | |
Car Charge | 12V 8A(7-8h 80%) | |
Panel | ||
Main Switch Button | Yes | |
AC | 10A*2 | |
AC-2(30A) | NA | |
Ac output power button | Yes | |
USB-A | 12W*2 | |
USB-A(Fast Charge) | 24W*1 | |
USB-C | 100W*1 | |
Cigarette Output | 120W*1(12V 10A) | |
DC | 12V 5A*2 | |
Wireless Charge | Optional(15W) | |
Bluetooth/Wifi(APP) | Optional | |
AC Charging Port(Adaptor DC) | Yes | |
Solar Power/Car Charging Port | 200W*1 | |
Parallel Port | NA | |
Display | Yes | |
Floodlight | Yes | |
Output AC Overcharge Protector | Yes | |
DC Output Power Button | Yes | |
Charge For CAR losing electricity | NA | |
High precision display of Electric Power(1%) | Yes | |
Error Code | Yes | |
Other specification | ||
Discharge | ||
100% load | 33 min | |
75% load | 44min | |
50% load | 66min | |
Dimension and Packages | ||
Unit Dimension | 299*205*234mm | |
Package Dimension | 335*240*290mm | |
Net Weight | 8.9KG | |
Gross Weight | 10.83 | |
UN box weight | 12 | |
40HQ Qty | 2835 | |
Life | 2000 Cycle | |
Accessory | Power Cord, Manual, Car Charge Cable | |
Certificate | UN38.3, ETL,FCC,CE, EMC |
