Specifications
SPECIFICATIONS
Basic Specifications | ||
Model | DPS1200L-Bmax | |
Capacity | 1075Wh / 25.6V 42Ah (equivalent to 12.8V 84Ah) | |
AC Voltage | 240V | |
Rated Power | 1200W | |
Surge Power | 2400W | |
THD | ≤3% | |
Cell Type | LiFePO4 (32700 3.2V 6AH) | |
Work Temp | Discharge -10-40℃ Charge 0-40℃ | |
PV Voltage Range | 12-60v | |
PV Charge Power | Max60V 400W | |
Wall Charge Power | 800W | |
Charge Methods | ||
Utility Power Charge Time | 800W (1h 80%) | |
Solar Charge Time | max 400w (2h 80%) | |
Generator Charge | 800W (1h 80%) | |
Car Charge | 12V 8A (11h 80%) | |
Panel | ||
Main Switch Button | Yes | |
AC | 10A*2 | |
AC-2(30A) | NA | |
Ac output power button | Yes | |
USB-A | 12W*2 | |
USB-A(Fast Charge) | 24W*2 | |
USB-C | 100W*2 | |
Cigarette Output | 120W*1(12V 10A) | |
DC | 12V 5A*2 | |
Wireless Charge | Optional(15W) | |
Bluetooth/Wifi(APP) | Optional | |
AC Charging Port(Adaptor DC) | Yes | |
Solar Power/Car Charging Port | 400W*1 | |
Parallel Port | Yes | |
Display | Yes | |
Floodlight | NA | |
Output AC Overcharge Protector | Yes | |
DC Output Power Button | Yes | |
Charge For CAR losing electricity | Yes | |
High precision display of Electric Power(1%) |
Yes | |
Error Code | Yes | |
Other specification | ||
Discharge | ||
100% load | 33min | |
75% load | 44min | |
50% load | 67min | |
Dimension and Packages | ||
Unit Dimension | 376x216x265 | |
Package Dimension | 455x295x365 | |
Net Weight | 16.2kg | |
Gross Weight | 17.8KG | |
UN box weight | 22 | |
40HQ Qty | 1080 | |
Life | 2000 Cycle | |
Accessory | AC Charge Cable, Car Charge Cable, Manual | |
Certificate | UN38.3, ETL,FCC,CE, EMC |
